AGCO SimplEbale User Manual

Step Diagnostic Result Action
2 Does the compression
cycle status indicator
illuminate on the Baler
Diagnostics page of the
terminal?
Yes For 1844 models: See
Hydraulics system not
building pressure
diagnostics.
No Refer to your approved
dealer.
5.3.9 CAN bus diagnostics
The CAN bus keypad does not operate correctly
Step Diagnostic Result Action
1 Do some of the first LEDs
on the keypad buttons
come ON when you set
the machine to ON?
Yes See General CAN bus
diagnostics.
No Go to step 2.
2 Do the keypad lamps
come ON when you set
the machine to ON?
Yes See General CAN bus
diagnostics.
No Do a check of fuse 6,
replace if it is necessary.
3 Is there power to the CAN
bus keypad?
Yes Go to step 4.
No Go to step 4.
4 Use a multimeter to do a
check of the CAN bus
keypad connector. Can
the multimeter find a 12 V
electrical current?
Yes Refer to your approved
dealer.
No Do a check of fuse 6,
replace if necessary.
General CAN bus diagnostics
Step Diagnostic Result Action
1 Are the 2 resistors
installed on the CAN bus?
There is a resistor at the
aft of the baler and a
resistor on the cab
harness connector.
Yes Go to step 2.
No Install the 2 resistors on
the CAN bus.
5 Troubleshooting
SimplEbale
89
