Step Diagnostic Result Action
5 Set the manual mode to
ON and set the manual
voltage to 5 V. Does an
object made from iron
attach to the solenoid?
Yes Go to step 6.
No Do a check of the wiring
harness. If there is
damage to the wiring
harness, repair or replace
the wiring harness.
6 Calibrate the hydraulic
valve. Does pressure
increase in the hydraulic
system?
Yes Diagnostics complete.
No Go to step 7.
7 Do a check of the
hydraulic density cylinder.
Does it operate correctly
with no leaks?
Yes Go to step 8.
No Replace the hydraulic
density cylinder.
8 Do a check of the oil
pump reservoir. Is the
level of oil correct?
Yes Go to step 9.
No Add oil.
9 Do a check of the
hydraulic hoses. Are there
leaks or failures on the
hoses?
Yes Repair the hydraulic
hoses.
No Go to step 10.
10 Do a check of the drive
mechanism for the oil
pump. Does it operate
correctly?
Yes Go to step 11.
No Replace the oil pump
drive chain.
11 Rotate the oil pump and
do a check if it operates
correctly. Is the internal
key in good condition and
operating correctly?
Yes Go to step 12.
No Replace the oil pump.
12 Do a check of the
hydraulic valve. Are there
unwanted objects in the
valve stems?
Yes Clean the hydraulic valve
and remove the unwanted
objects.
No Refer to your approved
dealer.
Bale chamber pressure reduction does not function correctly
Step Diagnostic Result Action
1 Is the PTO speed less
than 70% of the standard
PTO speed?
Yes Go to step 2.
No Decrease the PTO speed.
5 Troubleshooting
88
