5. INSTALLATION HI ROLLER - BELT CONVEYORS
5.9. HAZARD MONITORING DEVICES HI ROLLER, MINI ROLLER, LO ROLLER & HI LIFE
60 P115506 R3
SNUBBER HEAD SECTION (Figure 5.35)
• The head pulley and belt alignment can be monitored with one rub block
installed near the top centerline of the head pulley to detect a belt and head
pulley misalignment.
• The snubber pulley and return belt alignment can be monitored with one rub
block installed near the top centerline of the snubber pulley and will detect a
return belt misalignment and snubber pulley misalignment.
Figure 5.35
