64 1260 Infinity Micro Degasser Service Manual
8 Repairs
Exchanging Internal Parts
Exchanging Internal Parts
The procedures in this section describe how to exchange internal parts.
You must remove the micro vacuum degasser from the stack in order to
open the main cover.
Tabl e 6 Exchanging Internal Parts
Procedure Typical Frequenca Notes
“Exchanging a Vacuum
Chamber” on page 68
If defective Yellow status lamp, pressure
reading above 600 mV
“Exchanging the Vacuum
Pump” on page 70
If electrically defective Pressure reading above 600 mV or
vacuum pump not running
“Exchanging the Proportional
Valve” on page 72
If defective or leaking Pressure reading above 500 mV
“Exchanging the Vacuum
Tubings” on page 74
“Exchanging the Degasser Control
Assembly and the Sensor
Assembly” on page 76
If defective Low voltage at control assembly
