62 1260 Infinity Micro Degasser Service Manual
7 Maintenance
Introduction to Maintenance and Repair
Exchanging the Status Light Pipe
1 The status light pipe is clipped into the top cover.
2 Replace the top cover, see “Removing and Refitting the Top Cover” on
page 55.
When If part is broken
Tools required Screwdriver Pozidriv #1
Parts required # p/n Description
1 5041-8384 Status light pipe
Preparations • Remove the front cover and top cover, see “Removing and Refitting the Top Cover” on page 55.
