60 1260 Infinity Micro Degasser Service Manual
7 Maintenance
Introduction to Maintenance and Repair
Exchanging the Fuses of the Power Inline Filter
1 Switch off the power switch at the front of the instrument.
2 Remove the power cable from the power connector at the rear of the
instrument.
When When defective
Tools required None
Parts required # p/n Description
2 2110-0458 Fuse: 250V, T 500 mA , compatible to all supported line voltages
Use of unsupplied cables
Using cables not supplied by Agilent Technologies can lead to damage of the
electronic components or personal injury.
➔ Never use cables other than the ones supplied by Agilent Technologies to ensure
proper functionality and compliance with safety or EMC regulations.
The Agilent 1260 Infinity micro vacuum degasser power supply has wide-ranging capability
(see Ta b le 1 on page 11). It accepts any line voltage in the range mentioned in the table.
Consequently there is no voltage selector in the rear of the Agilent 1260 Infinity micro
vacuum degasser. There are two externally accessible fuses, that protect the power supply.
These fuses are identical for all accepted line voltages.
