1260 Infinity Micro Degasser Service Manual
81
Parts and Materials for Main
tenance
9
Sheet Metal Kit
Sheet Metal Kit
Figure
21
Sheet Metal Kit
Item
p/n
Description
1
G1379-68702
Sheet metal kit G13
79B
includes base and top plate
&
80
82
