1260 Infinity Micro Degasser Service Manual 21
Installing the Micro Vacuum Degasser
3
Flow Connections to the Micro Vacuum Degasser
Flow Connections to the Micro Vacuum Degasser
1 Place solvent cabinet with the bottle(s) on top of the micro vacuum
degasser.
2 Remove the front cover by pressing the snap fasteners on both sides.
Figure 6 Removing the Front Cover
Parts required Description
Solvent cabinet including solvent bottles (filled with solvent) and bottle head assemblies
Solvent outlet tubes
Syringe with adapter
Hardware required Micro degasser
Preparations Install the micro vacuum degasser
When opening capillary or tube fittings, solvents may leak out.
The handling of toxic and hazardous solvents and reagents can carry health risks.
➔ Observe appropriate safety procedures (for example, wear goggles, safety gloves
and protective clothing) as described in the material handling and safety data sheet
supplied by the solvent vendor, especially when toxic or hazardous solvents are
used.
