Agilent Technologies 34405A User Manual

Getting Started Tutorial 1
34405A User’s and Service Guide 25
Testing Continuity
• Measurement Method: 0.83 mA ± 0.2% constant current source, < 5 V open
circuit voltage.
• Response Time: 70 samples/ second with audible tone
• Continuity Threshold: 10 Ω fixed
• Input Protection: 1000 V (HI terminal)
Checking Diodes
• Measurement Method: Uses 0.83 mA ± 0.2% constant current source, < 5 V
open circuit voltage.
• Response Time: 70 samples/ second with audible tone
• Input Protection: 1000 V (HI terminal)
Shift
Cont )
)
)
Open Circuit Display:
12 A
rms
1000VDC
500Vpk
1.2A
rms
1.25A /500V FH
LO
CAT II (300V)
75 0VAC
HI
I
V
12 A
Fused
Open or
Closed
Circuit
Test
Current
Typical Closed Circuit Display:
Shift Freq
Freq
Reverse Bias or Open Diode Display:
12A
rms
1000VDC
500Vpk
1.2A
rms
1.25A/500V FH
LO
CAT II (300V)
750VAC
HI
I
V
12A
Fused
Forward Bias
Test
Current
VDC
Typical Forward Biased Diode Display:
34405A users guide.book Page 25 Saturday, September 2, 2006 3:38 PM
