96 34405A User’s and Service Guide
4 Performance Tests and Calibration
DC Voltage Gain Adjustment Procedure
Review the “Test Considerations” on page 71 and “Gain
Adjustment Considerations” on page 95 sections before
beginning this procedure.
1 Press to enter DC Voltage Gain Calibration.
2 The primary display will show the uncalibrated value and
the secondary display will show the reference value of the
Cal Item.
3 Configure each Cal Item shown in the adjustment table
below.
4 Use (Auto) or (Range) to select the Cal
Item.
Ta ble 1 4 Valid Gain Adjustment Input Values
Function Range Valid Amplitude Input Values
DC Volts 100 mV, 1 V, 10 V, 100 V, 1000 V 0.9 to 1.1 x Full Scale
DC Current 10 mA, 100 mA, 1000 mA, 10 A 0.9 to 1.1 x Full Scale
Ohms 100 Ω, 1 kΩ, 10 kΩ, 100 kΩ, 1MΩ, 10 M Ω 0.9 to 1.1 x Full Scale
Frequency Autorange/1 kHz Input
≥ 100 mV rms, 900 Hz to 1100 Hz
AC Current 1 mA, 10 mA, 100 mA, 1000 mA, 10 A 0.9 to 1.1 x Full Scale
AC Volts 10 mV, 100 mV, 1 V, 10 V, 100 V, 750 V 0.9 to 1.1 x Full Scale
Capacitance 0.4 nF, 1 nF, 10 nF, 100 nF, 1 µF, 10 µF,
100 µF, 1000 µF, 10000 µF
0.9 to 1.1 x Full Scale
DCV
NOTE
If the zero adjustment procedure has been recently performed prior to the
DC Voltage gain calibration procedure, the Cal Item 'Short' can be
neglected.
