Agilent Technologies 34410A - Measurement and System Speeds

34410A/11A User’s Guide 131
Specifications 5
Measurement and System Speeds
DMM Measurements Speeds
[1] ½ scale input signal, immediate trigger, trigger delay 0, autozero off, autorange off, no math,
60 Hz line, null off, sample count 1, trig count 1
Direct I/O Measurements
[1]
Single Reading – Measure and I/O Time
Measurement
Into Memory
(Readins/Sec)
(VM Complete)
Function Resolution
(NPLC)
GPIB
Sec
USB 2.0
Sec
LAN (VXI-11)
Sec
LAN (Sockets)
Sec
DCV (10 V Range) 0.006 0.0030 0.0036 0.0050 0.0035 10000
0.06 0.0035 0.0044 0.0048 0.0043 1000
1 0.0200 0.0200 0.0200 0.0200 60
ACV (10 V Range) Slow Filter 0.0100 0.0100 0.0100 0.0100 50
Medium Filter 0.0100 0.0100 0.0100 0.0100 150
Fast Filter 0.0100 0.0100 0.0100 0.0100 500
2–Wire W (10 kW Range) 0.006 0.0035 0.0036 0.0049 0.0035 10000
0.06 0.0043 0.0045 0.0049 0.0043 1000
1 0.0195 0.0200 0.0200 0.0200 60
4–wire W (10 kW Range) 0.006 0.0054 0.0040 0.0045 0.0056 1200
0.06 0.0074 0.0078 0.0078 0.0074 380
1 0.0390 0.0390 0.0390 0.0390 30
Frequency
1 KHz, 10 V Range
Fast Filter
1 ms Gate 0.0100 0.0100 0.0100 0.0100 500
10 mS Gate 0.0200 0.0200 0.0200 0.0200 80
100 mS Gate 0.1150 0.1150 0.1130 0.1130 10
1 S Gate 1.0200 1.0200 1.0200 1.0200 1
Capacitance (100 nF Rage) 0.0820 0.0820 0.0820 0.0820 11
