34410A/11A User’s Guide 9
The Rear Panel at a Glance
WARNING
For protection from electrical shock, the power cord ground must not be defeated.
1 Power cord receptacle
2 Power-line fuse holder
3 Line voltage indicator
4 Current input fuse holder
5 LAN cable receptacle
6 USB cable receptacle
7 GPIB cable receptacle
8 HI Sense Terminal (also 4-wire
Ω)
9 LO Sense Terminal (also 4-wire Ω)
10 HI Input terminal
11 LO Input terminal
12 Current Input terminal
13 External Trigger terminal
14 VM Comp (reading complete) terminal
