Chapter 7: Replaceable Parts
Replaceable Parts List
7–12
Electrical Assemblies
A2 0950-4369 1 POWER SUPPLY
A5 0950-3235 1 INVERTER BOARD
A13 2090-0396 1 LCD DISPLAY
PC Motherboard (Motorola Motherboard w/1.44 MByte Floppy Drive and CD ROM Drive)
A4 86100-66517
54810-66541
1
1
CDROM ADAPTER BOARD (NOT ON OPTION 017)
CDROM ADAPTER BOARD (WITH OPTION 017)
A6 0950-4411 1 CD ROM R/W
A7 0950-4362 1 3.5 INCH FLOPPY DRIVE
A8 0950-4166 1 HARD DRIVE (NOT ON OPTION 017)
A8 54855-83501 1 HARD DRIVE w/SOFTWARE (NOT ON OPTION 017)
A19 0960-2176 1 MOTHERBOARD SUBASSEMBLY (DOES NOT INCLUDE DIMM)
H22 0624-0847 3 SELF TAPPING SCREWS
W13 54801-61643 1 HARD DRIVE MINI IDE CABLE (NOT ON OPTION 017)
W14 54810-61615 1 HARD DRIVE GROUND CABLE (NOT ON OPTION 017)
W15 54810-61611 2 IDE HARD DRIVE CABLE
W16 54810-61616 1 CDROM AUDIO CABLE
All Configurations
A9 54810-66506 1 PROBE INTERFACE BOARD
A10 54810-66529 1 WAVEFORM DISPLAY BOARD
A11 54810-66525 1 DISPLAY BOARD
A12 82350BI 1 PCI GPIB BOARD
A15 54810-66511 1 AUTO PROBE I/F
A17 54810-66507 1 KEYBOARD - CURSOR
A18 54855-66506 1 KEYBOARD - 4CH
A21 54855-66510 1 PCI BRIDGE BOARD
Fans
B1 3160-4134 6 12 V FAN
Internal Chassis Parts
H1 0515-2219 3 MACHINE SCREW 5 MM
H2 54503-25701 5 HEX NUT BNC
H3 0515-1025 4 PAN HEAD SCREW 26 MM
H4 0515-1410 6 PAN HEAD SCREW 20 MM
H5 0515-0430 11 PAN HEAD SCREW 6 MM
H6 0515-0372 21 PAN HEAD SCREW 8 MM
H7 0515-1246 2 PATCH LOCK SCREW 6 MM
H8 5021-4302 2 M4x0.7 20MM-LG PANHD PATCHLOCK BLACK
H9 54801-24702 2 RETAINER STRAP HANDLE
H10 0515-2195 8 PAN HANDLE SCREW 40 MM
H11 0515-1103 10 FLAT HEAD SCREW
H12 0515-0380 18 PAN HEAD SCREW
H13 0515-1403 4 M4X0.7 6 MM 90DEG FLATHD T15
H14 0515-0436 4 MS M4x0.7 18 MM LG SCREW (NOT ON OPTION 017)
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
To Next Page
