Chapter 7: Replaceable Parts
Replaceable Parts List
7–13
H15 0515-0375 3 MS MSx0.5 16 MM LG
H16 0515-0365 5 SCR MACHINE
H18 0515-2691 2 MS M2.6X0.45 6 MM PAN HEAD
H19 54542-26101 1 GROUND LUG
H20 2190-0027 1 WIL.256 .478 .02
H21 2950-0072 1 NUTH 1/4-32 .062
H25 0515-0666 10 M3 SCREW
H26 0515-0368 16 M2.5x12MM SCREW
H27 2190-0068 2 WASHER
H28 2950-0054 2 NUT
H29 0515-0433 4 M4X0.7 8MM SCREW; TORX T20
MP1 54810-01212 6 FAN CLIP
MP2 54855-00501 1 SLEEVE BOTTOM
MP3 54855-60101 1 CHASSIS ASSEMBLY
MP4 54855-60102 1 ATX TRAY
MP5 54810-01211 1 HARD DRIVE BRACKET (NOT ON OPTION 017)
MP6 54810-03701 1 CDROM SUPPORT RAIL
MP7 54810-01214 1 CDROM MOUNT BRACKET
MP8 54810-04103 1 FRONT FRAME BACK PLATE
MP9 54801-40502 1 FRONT FRAME
MP10 54810-01213 1 POWER SUPPLY SUPPORT BRACKET
MP11 54801-88001 1 LENS GLASS
MP12 54801-01205 2 LENS BRACKET
MP23 54801-24701 1 BRACKET STIFFENER
MP25 54801-09101 1 SPRING STEEL
MP27 54855-41901 1 KEYPAD 4CH
MP29 54810-41902 1 CURSOR KEYPAD
MP30 54801-01206 1 CAL BNC BRACKET
MP33 54810-04104 1 SLEEVE TOP
MP39 1520-0238 4 GROMET (NOT ON OPTION 017)
MP41 54810-03703 1 CD-SUPPORT RAIL STOP
MP42 1400-3242 1 CABLE CLAMP
MP43 54832-09102 1 DISPLAY SPRING
MP44 54832-09103 1 POWER SUPPLY SPRING COVER
MP45 54810-42203 4 GROMMET 9x38
MP46 54810-42204 1 GROMMET 9x64
MP47 54810-42202 1 GROMMET 20x50
MP48 54855-61101 4 HEAT SINK
MP49 54857-60201 1 REMOVEABLE HARD DRIVE COVER PLATE (NOT ON OPTION 017)
MP50 54857-01216 1 REMOVEABLE HARD DRIVE BRACKET (NOT ON OPTION 017)
Cables
W3 54826-61606 1 ACQUISITION SIGNAL CABLE
W4 54855-61604 1 POWER HARNESS CABLE
W5 54855-68803 1 POWER INPUT/LINE SINC
W6 54810-61613 1 CABLE ASSEMBLY POWER SUPPLY
W7 54810-61609 1 MOTHERBOARD SWITCH CABLE
W8 54810-61606 1 AUTO PROBE INTERFACE CABLE
W9 54855-61617 1 SEMI-RIGID CAL CABLE
W10 54801-61634 1 PROBE COMP CABLE
W11 54810-61610 1 DISPLAY CABLE
Replaceable Parts
Ref.
Des.
Agilent Part
Number QTY Description
To Next Page
