Operating in EI Mode 4
5977B Series MSD Operating Manual 117
5 Verify that the MSD power cord is plugged into a grounded building’s main
receptacle.
6 Turn on the MSD by pressing the On/Off switch on the front of the MSD.
7 Press lightly on the side board to ensure a correct seal. Press on the metal
box on the side board.
8 Close the vent valve when it makes a hissing sound. (See Figure 39.)
The foreline pump will make a gurgling noise. This noise should stop within a
minute. If the noise continues, there is a
large air leak in your system,
probably at the side plate seal, the interface column nut, or the vent valve.
9 Start the Agilent MassHunter GC/MS Acquisition software.
10 In the Instrument Control view, from the Instrument menu, select MS Vacuum
Control to display the Vacuum Control dialog. (See Figure 40 on page 118.)
Figure 39 Vent valve knob
