6 General Maintenance
178 5977B Series MSD Operating Manual
Figure 57 Disassembling the EI XTR source
Table 2 0 Parts list for EI XTR source (Figure 57)
Item Description Part number
1 Setscrews G3870-20446
2 Screws G3870-20021
3 Source body G3870-20440
4 Extractor lens G3870-20444
5 Extractor lens insulator G3870-20445
6 Filaments G7005-60061
7 Spring washer 3050-1301
