62 5977B Series MSD Operating Manual
3 Intuvo 9000 GC Column Maintenance
4 Open the GC front door.
5 Open the bus door and remove it by lifting the door vertically off its hinge
pins.
6 Lower the oven door.
7 Using the Intuvo torque driver, rotate all four column clamps off the
column's retainer ring.
Figure 11 9000 GC front door, bus door, oven door, and Intuvo torque driver
Bus door
Oven door
Intuvo torque driver
Front door
