Intuvo 9000 GC Column Maintenance 3
5977B Series MSD Operating Manual 63
8 Unplug the column SmartID key from the lower USB port.
9 Using the Intuvo torque driver, remove the two compression bolts that seal
the column's click and run connectors to the bus and store for later use.
10 Remove and store the column for later use in accordance with the column
manufacturer's recommendations.
Figure 12 9000 GC column and related parts
SmartID key
Column clamps
Retainer ring
Compression bolts
Click and run connectors
