Maintaining the GC/MS Interface
The GC/MS interface requires no periodic maintenance
Rarely, the heater cartridge in the GC/MS interface fails. In those cases, it is
necessary to replace the heater and sensor. This section contains procedures
for removing the heater and sensor and installing new ones. See Figure 15.
Figure 15 GC/MS interface
MS GC oven
Ionization chamber
Heater/sensor assembly
Analyzer chamber
Heater sleeve
Insulation
