166 Troubleshooting and Maintenance Manual
8 Electronics
Power Switch
See also
The GC/MS MassHunterWorkstation in the Getting Started manual.
Power switch
The power switch is located on the lower left of the front of the MS. It is
separate from the electronics module and is connected via a cable. It is used to
turn the MS and foreline pump on and off.
Do not switch the MS off unless it has completed the vent program. Incorrect
shutdown can seriously damage the MS.
Figure 35 Front of the MS
Local control panel
Power switch
