Agilent Technologies 7000 Triple Quadrupole GC/MS

12 Troubleshooting and Maintenance Manual
1 Introduction
Triple Quad GC/MS Hardware Description
Figure 1 is an overview of a typical 7000 Triple Quad GC/MS system.
Figure 1 7000 Triple Quad MS
ALS
7000 Series Triple
Quad MS
Local control
panel
MS power
switch
7890A GC
Tra y
GC power switch
