178 Troubleshooting and Maintenance Manual
8 Electronics
Back Panel Connectors
The back panel contains several connectors (Figure 42) and the four primary
fuses.
Figure 42 Back panel connections
Fuses
Turbo pump power
Foreline pump power
Turbo controller/fan
Main power cord
Vacuum gauges
Remote
start/stop
LAN
communications
