Agilent Technologies 7000 Triple Quadrupole GC/MS User Manual

165
Agilent 7000 Series Triple Quadrupole GC/MS
Troubleshooting and Maintenance Manual
Agilent Technologies
8
Electronics
Power Switch 166
Ion Source Board 167
Quadrupole Boards 168
Collision Cell Board 169
Detector Board 170
Electronics Module 171
Bus board 176
PLX card 176
LAN/MS Control Card (Smartcard 4) 176
Power Supplies 177
Back Panel Connectors 178
Interfacing to External Devices 180
The following assemblies make up the MS electronics:
Except for the Back panel and connectors, and Interfacing to external
devices sections, most of this material is not essential for day-to-day operation
of the GC/MS. It may be of interest to persons responsible for servicing the
GC/MS.
WARNING
Dangerous voltages are present under the safety covers. Do not remove safety
covers. Refer servicing to your Agilent Technologies service representative.
