5 CI Maintenance
CAUTION
After removing the calibrant vial, you must purge the calibration valve. Failure to do so
will result in severe contamination of the ion source and damage to the filament and
electron multiplier.
Figure 18 CI calibration valve and vial
Calibration valve
Calibration vial
Collar
