Replacement Parts 9
Troubleshooting and Maintenance Manual 187
Printed circuit boards
Table 9 Printed circuit boards
Description Part number
Quad driver assembly (2) G7000-65015
Filament drive board G7000-61100
Collision cell board G7000-61005
Detector feedthrough board G7000-61011
Motherboard, 1 GHz, 1 GB memory 0960-2490
SDRAM, 256 MB 1818-8947
PLX board G2571-61001
4 GByte USB drive G7000-80200
Main board G7000-61001
SC4 bus G7000-61008
Log amp G3170-65101
Extender board, PCI, 32 bit 0403-1169
Table 1 0 Power supplies and related parts
Description Part number
Toroid transformer G7000-60229
Power supply, AC/DC, 4 output 0950-4826
AC board, LC-TOF G2597-61017
Power supply, EMV G7000-80016
Power supply, HED, unipolar G3170-80017
Power supply, HED, bipolar G3170-80018
Power supply, Turbo pump G7000-60600
