7 General Maintenance
To Open the Front Analyzer Chamber
158 7000/7010 Series TQ GC/MS Operating Manual
Figure 47. The front analyzer chamber on a 7010 MS
Ceramic source board
Ion source
Side plate
Post-filter
Front analyzer
Chamber closed
Quad driver boards Front analyzer side plate
Thumbscrews
Rear analyzer side plate
