8CI Maintenance
To Install the EI HES Radiator
214 7000/7010 Series TQ GC/MS Operating Manual
To Install the EI HES Radiator
Materials needed
• Gloves, clean, lint-free (Large 8650-0030) (Small 8650-0029)
• T10 Torx screwdriver (5182-3466)
• Tweezers (8710-2460)
Procedure
1 Place the radiator over the guide pins on the analyzer support and use a T10
Torx screwdriver to secure it using the (2) M3 × 12 gold plated screws
(G7002-20110). (See Figure 72 on page 215.)
2 Attach the wires to the radiator or CSB. Do not bend the wires any more than
necessary. (See “To Connect or Disconnect EI HES Radiator Wiring” on
page 210.)
The analyzers, GC/MS interface, and other components in the analyzer
chamber operate at very high temperatures. Do not touch any part until you
are sure it is cool.
Always wear clean gloves to prevent contamination when working in the
analyzer chamber.
Use an antistatic wrist strap, and take other antistatic precautions before
touching analyzer components.
