8CI Maintenance
To Install the CI/EI XTR Source Radiator
7000/7010 Series TQ GC/MS Operating Manual 223
To Install the CI/EI XTR Source Radiator
Materials needed
• Gloves, clean, lint-free (Large 8650-0030) (Small 8650-0029)
• Tweezers (8710-2460)
• T10 Torx screwdriver (5182-3466)
Procedure
1 Align the radiator over the two guide pins on the analyzer support, and secure
it using the two retained screws with a number T10 Torx screwdriver. Make
sure the insulators are in place under the screws.
The analyzers, GC/MS interface, and other components in the analyzer
chamber operate at very high temperatures. Do not touch any part until you
are sure it is cool.
Always wear clean gloves to prevent contamination when working in the
analyzer chamber.
Use an antistatic wrist strap, and take other antistatic precautions before
touching analyzer components.
When disconnecting leads, pull on the connectors, not on the wires.
