Chapter 2 2-131
System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
10. Uncorrected Port Performance
The analyzer can perform error-correction and store the error coefficients. These error
coefficients are, in fact, measurements of the analyzer’s uncorrected port performance.
NOTE The crosstalk error terms are omitted in this procedure. They are covered in
the “Test Port Crosstalk” performance test.
Analyzer warm-up time: 30 minutes
Specifications
Required Equipment
Uncorrected
a
Error Terms
a. At 25 °C ±5 °C, with less than 1°C deviation from the measurement calibration
temperature.
Frequency Range
300 kHz to 1.3 GHz 1.3 GHz to 3 GHz
3 GHz to 6 GHz
b
b. Only for analyzers with Option 006.
Directivity 30 dB 24 dB 19 dB
Source Match
(Standard)
25 dB 20 dB 14 dB
Source Match
(Option 004)
23 dB 18 dB 14 dB
Load Match (raw) 24 dB 19 dB 16 dB
Reflection Tracking ±1.0 dB ±1.0 dB ±2.0 dB
Transmission
Tracking
±1.5 dB ±1.5 dB ±2.5 dB
Description HP/Agilent Part or Model Number
Calibration Kit: 50Ω, Type-N 85032B
Cable: Type-N, 24-inch 8120-4781
