Agilent Technologies 8720ES Service Guide

2-22 Chapter 2
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
4. Test Port Output Power Linearity
This test verifies the analyzer’s test port output power linearity throughout the analyzer’s
frequency range. A power meter calibration is used to set the reference output power
across the frequency range of the analyzer. The analyzer’s B-channel receiver is used to
determine power linearity after each change in output power.
NOTE This test does not verify the functionality of the step attenuator. To verify its
function, go to “Step 2. Operator's Check” on page 4-6.
Analyzer warm-up time: 30 minutes
Specifications
Required Equipment
Power Range
Power Level Linearity
a
a. Relative to 0 dBm from 300 kHz to 3 GHz
(2 GHz for Option 075; 6 GHz for Option 006).
−15 to +5 dBm ±0.2 dB
+5 to +10 dBm ±0.5 dB
+5 to +8 dBm
b
b. Options 014 and 075
±0.5 dB
Description HP/Agilent Part or Model Number
Power Meter 437A/438A or E4418B/4419B
Power Sensor 8482A
Adapter: APC-7 to type-N (f) 11524A
Attenuator: APC-7, 50Ω, 20 dB 8492A Option 020
RF Cable: APC-7, 50Ω 8120-4779
GPIB Cable 10833A/B/C/D
Additional Equipment for Option 006 Analyzers
Power Sensor 8481A
Additional Equipment for Option 075 Analyzers
Attenuator: 20dB, Type-N 8491A Option 020
Minimum Loss Pads (2): 50Ω to 75Ω 11852B
Cable: 50Ω, Type-N(m) to Type-N (m) 8120-4781
Power Sensor 8483A (Option H03)
