13-30 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ES: Cables, Front
Ref.
Desig.
Opt
Type
a
a. nW = Wire Bundle (n is the number of wires in the bundle)
nR = Ribbon Cable (n is the number of wires in the ribbon)
SR = Semi-Rigid Coax Cable
HP/Agilent
Part Number
Qty Description
A1W1 30R 8120-8439 1 FP KEYBOARD (A1J1) to FP INTERFACE (A2J2)
RPG1W1 5R (part of RPG1) 1 RPG to FP INTERFACE (A2J5)
W1 SR 08753-20952 1 SOURCE ASSY (A3W4) to TRANSFER SWITCH
(A24)
W2 SR 08753-20290 1 FP (R CHANNEL IN) to SAMPLER-R (A4)
W3 SR 08753-20286 1 TEST PORT 1 COUPLER (A21)
to SAMPLER-A (A5)
W4 SR 08753-20953 1 TEST PORT 2 COUPLER (A22)
to SAMPLER-B (A6)
W17 50R 8120-8431 1 FP INTERFACE (A2J1) to MOTHERBOARD (A17J1)
W18 3W 08753-60364 1 FP INTERFACE (A2J4) to FP (PROBE POWER)
W19 3W 08753-60364 1 FP INTERFACE (A2J3) to FP (PROBE POWER)
W22 5R 8120-8842 1 FP INTERFACE (A2J7) to INVERTER (A27)
W23 31R 8120-8409 1 FP INTERFACE (A2J6) to DISPLAY (A18)
W24 SR 08753-20291 1 SOURCE ASSY (A3) to FP (R CHANNEL OUT)
W25 SR 08720-20075 1 FP (R CHANNEL OUT) to FP (R CHANNEL IN)
1 014 SR
08753-20179
1 CABLE, A SAMPLER IN to A SAMPLER
2 014 SR
08753-20954
1 CABLE, B SAMPLER IN to B SAMPLER
3 014 SR
08753-20951
1 CABLE, SOURCE to RF OUT
