13-18 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ET: Cables, Top
Ref.
Desig.
Opt
Type
a
a. nW = Wire Bundle (n is the number of wires in the bundle)
nR = Ribbon Cable (n is the number of wires in the ribbon)
F = Flexible Coax Cable
SR = Semi-Rigid Coax Cable
HP/Agilent
Part Number
Qty Description
1 1400-0249 1 CABLE TIE (15W1 to CHASSIS)
A15W1 18W (part of A15) 1 PREREGULATOR (A15) to POST REGULATOR
(A8J2) and MOTHERBOARD (A17J3)
W1 SR 08753-20363 1 SOURCE ASSY (A3W7) to DUAL DIRECTIONAL
COUPLER (A21)
W2 SR 08753-20290 1 FP (R CHANNEL IN) to SAMPLER-R (A4)
W3 SR 08753-20361 1 DUAL DIRECTIONAL COUPLER (A21) to
SAMPLER-A (A5)
W4 SR 08753-20364 1 TRANSMISSION PORT to SAMPLER-B (A6)
W5 F 08753-60027 1 SAMPLER-R (A4) to PULSE GENERATOR (A7)
W6 F 08753-60027 1 SAMPLER-A (A5) to PULSE GENERATOR (A7)
W7 F 08753-60027 1 SAMPLER-B (A6) to PULSE GENERATOR (A7)
W8 F 08753-60029 1 PHASE LOCK (A11J1) to SAMPLER-R (A4)
W9 F 8120-5021 1 FRAC-N DIGITAL (A14J1) to PULSE GENERATOR
(A7)
W10 F 08753-60029 1 FRAC-N DIGITAL (A14J2) to REFERENCE (A12J1)
W11 F 08753-60029 1 FRAC-N DIGITAL (A14J3) to FRAC-N ANALOG
(A13J1)
W12 F 08753-60029 1 FRAC-N ANALOG (A13J2) to REFERENCE (A12J2)
W13 F 08753-60026 1 REFERENCE (A12J3) to RP (EXT REF)
W20 34R 8120-6890 1 MOTHERBOARD (A17J11) to CPU (A9J5)
W21 14R 8120-6876 1 MOTHERBOARD (A17J12) to REAR PANEL VGA
OUT
W24 004 SR 08753-20291 1 SOURCE ASSY (A3) to FP (R CHANNEL OUT)
W26 F 8120-5026 1 SOURCE ASSY (A3) to REFERENCE (A12J4)
