Agilent Technologies 8720ES Service Guide

13-40 Chapter 13
Replaceable Parts
Replaceable Part Listings
8753ET: Rear Panel Assembly
Ref.
Desig.
Opt
Type
a
a. nR = Ribbon Cable (n is the number of wires in the ribbon)
HP/Agilent
Part Number
Qty Description
1 34R 8120-6407
1
RP INTERFACE (A16J4) TO MB (A17J6) (W27)
3 (A16) 08720-60138
1
BD ASSY-REAR PANEL INTERFACE (A16)
4 08753-60026
1
ASSY-EXTERNAL REFERENCE CABLE (W13)
5 08415-60036
1
ASSY-FAN
6 1251-2942
4
FASTENER CONN RP LOCK
7 2190-0034
2
WASHER LK .194ID10
7 0380-0644
2
NUT STDF .327L 6-32
8 1251-7812
4
FASTENER CONN RP LOCK
9 0515-0379
4
SCREW SMM3.5X16 CWPNTX
9 3050-1192
4
FLAT WASHER
10 0515-0372
10
SCREW SMM3.0X8 CWPNTX
11 08720-00071
1
REAR PANEL SHEET METAL
12 3160-0281
1
FAN GUARD
13 6960-0419
1
HOLE PLUG
14 6960-0086
1
HOLE PLUG
15 2190-0102
8
WASHER LK .472ID
15 2950-0035
8
NUT HEX 15/32-32
16 0400-0271
1
GROMMET SN.5-515ID
17 6960-0027
4
HOLE PLUG
18 6960-0149
2
HOLE PLUG
19 1D5
HIGH STABILITY FREQUENCY REFERENCE
b
b. See “8753ET/ES: Rear Panel Assembly, Option 1D5” on page 13-44.
