Chapter 13 13-53

Replaceable Parts

Replaceable Part Listings

8753ET/ES: Hardware, Disk Drive Support

Figure 13-28 8753ET/ES: Hardware, Disk Drive Support

Ref.

Desig.

ET/ES Option HP/Agilent

Part Number

Qty Description

1 ET/ES 0515-1048 4 SCREW-M 2.5X4 SOCKET HEAD, HEX.

2 ET/ES 08753-00152 1 DISK DRIVE BRACKET

3 ET/ES 0515-0374 4 SCREWS -MACHINE M 3.0X10 CWPNTX

4 ET/ES 08753-40016 1 PLUG, DISK DRIVE
