14-26 Chapter 14
Assembly Replacement and Post-Repair Procedures
A9BT1 Battery
A9BT1 Battery
Tools Required
T-10 TORX screwdriver
ESD (electrostatic discharge) grounding wrist strap
soldering iron with associated soldering tools
Removal
1. Remove the A9 CPU board (refer to A9 CPU Board” on page 14-24).
2. Refer to Figure 14-12. Unsolder and remove A9BT1 from the A9 CPU board.
WARNING Battery A9BT1 contains lithium. Do not incinerate or puncture this
battery. Discard used batteries according to manufacturer’s
instructions.
Replacement
1. Make sure the new battery is inserted into the A9 board with the correct polarity.
WARNING Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended.
2. Solder the battery into place.
3. Replace the A9 CPU board (refer to A9 CPU Board” on page 14-24).
