Agilent Technologies 8720ES Service Guide

Chapter 2 2-155
System Verification and Performance Tests
Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
Option(s) Date
11. Test Port Receiver Magnitude Dynamic Accuracy (Test Port 1)
GF|G − F|
Test
Port
Input
Power
(dBm)
8496A
Attn.
(dB)
Real Part Imaginary Part Test Port
Measurement
(dB)
Expected
Measurement
(Corrected)
(dB)
Dynamic
Accuracy
(Calculated)
Spec.
(dB)
Meas.
Uncer.
(dB)
−10 0 ≤ 0.033 ± 0.008
−20
(ref)
10 0.000 ≤ 0.021 ± 0.008
−30 20 ≤ 0.031 ± 0.008
−40 30 ≤ 0.041 ± 0.008
−50 40 ≤ 0.054 ± 0.008
−60 50 ≤ 0.069 ± 0.017
−70 60 ≤ 0.111 ± 0.017
−80 70 ≤ 0.257 ± 0.017
−90 80 ≤ 0.741 ± 0.017
−100 90 ≤ 2.121 ± 0.027
