Agilent Technologies 8720ES Service Guide

1-6 Chapter 1
Service Equipment and Analyzer Options
Required Tools and Equipment
Adapters (2) APC-7 to Type-N (m) 11525A P
Adapter APC-7 to 3.5 mm (m) 1250-1746 A, P
Adapter APC-7 to 3.5 mm (f) 1250-1747 A, P
Adapter BNC to Alligator Clip 8120-1292 A
Adapter APC-3.5 (m) to Type-N (f) 1250-1750 A, P
Adapter APC-3.5 (f) to Type-N (f) 1250-1745 A, P
Adapter BNC (m) to Type-N (f) 1250-1477 P
Adapter Type-N (f) to Type-N (f) 1250-0777 P
Adapter Type-N (f) to Type-N (f), 75Ω 1250-1529 P
RF Cable Set APC-7, 50 Ω 11857D A, P
RF Cable (2) 24-inch, APC-7, 50 Ω (2) 8120-4779 A, P
RF Cable (for Option 075) 24-inch, Type-N, 75Ω 8120-2408 A, P
RF Cable 24-inch, Type-N, 50 Ω 8120-4781 A, P
GPIB Cable 10833A A, P
Coax Cable BNC (m) to BNC (m), 50Ω 10503A A
Coax Cable BNC 8120-1840 A, P
a. P = Performance Tests, A = Adjustments, T = Troubleshooting
Table 1-2 Agilent 8753ES Service Test Equipment
Required Equipment Critical Specifications HP/Agilent
Recommended Model
Use
