10-46 Chapter 10
Service Key Menus and Error Messages
Error Messages
NO CALIBRATION CURRENTLY IN PROGRESS
Error Number 69
The softkey is not valid unless a calibration is
already in progress. Start a new calibration.
NOT ENOUGH SPACE ON DISK FOR STORE
Error Number 44 The store operation will overflow the available disk space. Insert a new disk or purge
files to create free disk space.
NO FILE(S) FOUND ON DISK
Error Number 45 No files of the type created by an analyzer store operation were found on the disk. If
you requested a specific file title, that file was not found on the disk.
NO IF FOUND: CHECK R INPUT LEVEL
Error Number 5 The first IF signal was not detected during pretune. Check the front panel R channel
jumper. If there is no visible problem with the jumper, refer to
Chapter 7 , “Source
Troubleshooting.”
NO PHASE LOCK: CHECK R INPUT LEVEL
Error Number 7 The first IF signal was detected at pretune, but phase lock could not be acquired. Refer
to
Chapter 7 , “Source Troubleshooting.”
NO SPACE FOR NEW CAL. CLEAR REGISTERS
Error Number 70 You cannot store a calibration set due to insufficient memory. You can free more
memory by clearing a saved instrument state from an internal register (which may
also delete an associated calibration set, if all the instrument states using the
calibration kit have been deleted). You can store the saved instrument state and
calibration set to a disk before clearing them. After deleting the instrument states,
press to run the memory packer.
NOT ALLOWED DURING POWER METER CAL
Error Number 198 When the analyzer is performing a power meter calibration, the GPIB bus is
unavailable for other functions such as printing or plotting.
OVERLOAD ON INPUT A, POWER REDUCED
(ES only)
Error Number 58
See OVERLOAD ON INPUT R POWER REDUCED (error number 57).
OVERLOAD ON INPUT B, POWER REDUCED
(ES only)
Error Number 59
See OVERLOAD ON INPUT R POWER REDUCED (error number 57).
