Agilent Technologies 89410A - Page 93

External Arm
Measurement Lower Limit
(V)
Upper Limit
(V)
Measured Value
(V)
Pass/Fail
+2 Volt, Region Above
1.5 2.5
−2 Volt, Region Below
−2.5 −1.5
Harmonic Distortion
Measurement Lower Limit Upper Limit
(dBc)
Measured Value
(dBc)
Pass/Fail
9.75 MHz 2nd, Ch 1
−75
9.75 MHz 3rd, Ch 1
−75
9.75 MHz 2nd, Ch 2 †
−75
9.75 MHz 3rd, Ch 2 †
−75
3.33 MHz 2nd, Ch 1
−75
3.33 MHz 3rd, Ch 1
−75
3.33 MHz 2nd, Ch 2 †
−75
3.33 MHz 3rd, Ch 2 †
−75
† Option AY7 only
Serial Number:______________________Report Number:____________________
Agilent 89410A Verifying Specifications
Performance Test Record
7of14
