DATA Subsystem
Parameter Typical Return
<arb_name> is any valid file name. If omitted, the default <arb_name> is the arbitrary wave-
form currently active (selected with FUNCtion:ARBitrary).
+2.45036000E-
002
Return the mean of all points stored in "SINC".
DATA:ATTR:AVER?" INT:\BuiltIn\SINC.arb"
l Querying a waveform that does not exist generates a "Specified arb waveform does not exist" error.
l <arb_name> can be a file name (put in memory by MMEMory:LOAD:DATA[1|2]) or a name generated from
DATA:ARBitrary or DATA:ARBitrary:DAC.
[SOURce[1|2]:]DATA:ATTRibute:CFACtor? [<arb_name>]
Returns the crest factor of all data points for the specified arbitrary waveform segment in INTERNAL or USBmemory,
or loaded into waveform memory.
Parameter Typical Return
<arb_name> is any valid file name. If omitted, the default <arb_name> is the arbitrary
waveform currently active (selected with FUNCtion:ARBitrary).
+1.73205100E+000
Return crest factor of all data points stored in "NEG_RAMP".
DATA:ATTR:CFAC? "INT:\BuiltIn\NEG_RAMP.arb"
l Crest factor is the ratio of the peak value to the RMS value of the waveform.
l Querying a waveform that does not exist generates a "Specified arb waveform does not exist" error.
l <arb_name> can be a file name (put in memory by MMEMory:LOAD:DATA[1|2]) or a name generated from
DATA:ARBitrary or DATA:ARBitrary:DAC.
[SOURce[1|2]:]DATA:ATTRibute:POINts? [<arb_name>]
Returns the number of points in the specified arbitrary waveform segment in INTERNAL or USBmemory, or loaded
into waveform memory.
Parameter Typical
Return
<arb_name> is any valid file name. If omitted, the default <arb_name> is the arbitrary waveform
currently active (selected with FUNCtion:ARBitrary).
+40
Returns the number of data points in "EXP_RISE":
DATA:ATTR:POIN? "INT:\BuiltIn\EXP_RISE.arb"
l <arb_name> can be a file name (put in memory by MMEMory:LOAD:DATA[1|2]) or a name generated from
DATA:ARBitrary or DATA:ARBitrary:DAC.
190 Agilent 33500 Series Operating and Service Guide
