Introduction to Instrument
Introduction to Instrument
The Agilent Technologies 33500 Series is a series of synthesized waveform generators with built-in arbitrary waveform
and pulse capabilities.
Instrument at a Glance
Front Panel at a Glance
Front-Panel Display at a Glance
Front-Panel Number Entry
Rear Panel at a Glance
Contacting Agilent
Instrument at a Glance
The instrument's combination of bench-top and system features makes it a versatile solution now and in the future.
Convenient bench-top features
l 16 standard waveforms
l Built-in 16-bit arbitrary waveform capability
l Precise pulse waveform capabilities with adjustable edge time
l LCD display with numeric and graphical views
l Easy-to-use knob and numeric keypad
l Instrument state storage with user-defined names
l Portable, ruggedized case with non-skid feet
Flexible system features
l Downloadable 1M-point or optional 16M-point arbitrary waveform memory.
l USB, GPIB, and LAN remote interfaces (GPIB optional on models 33521A and 33522A)
l LXI Class C Compliant
l SCPI (Standard Commands for Programmable Instruments) compatibility
10 Agilent 33500 Series Operating and Service Guide
