Factory Reset State
Factory Reset State
The following tables show factory default settings. Parameters marked with a bullet (•) are non-volatile, and are not
affected by power cycling or *RST. Other parameters are volatile and reset to the indicated values at power-on or after
*RST.
The power-on/reset state may differ from that shown below if you have enabled power-on state
recall mode from the System menu. See Instrument State Storage.
Output Channel Configuration
Function Sine Wave
Tracking Off
Frequency 1 kHz
Frequency Mode CW
Frequency Couple
State
OFF
Frequency Couple
Mode
Ratio
Frequency Couple
Ratio
1
Frequency Couple
Offset
0
Amplitude 100 mVpp
Offset 0 VDC
Voltage Couple
State
OFF
Voltage Limit
State
OFF
Voltage Limit High 5 V
Voltage Limit Low -5 V
Voltage Unit VPP
Voltage Range AUTO
State OFF
Load 50 Ω
348 Agilent 33500 Series Operating and Service Guide
