HCOPy Subsystem
HCOPy Subsystem
The HCOPy subsystem produces screen images ("screen shots") of the front-panel display.
Example
The following example captures and returns the front-panel display image in BMP format.
HCOP:SDUM:DATA:FORM BMP
HCOP:SDUM:DATA?
HCOPy:SDUMp:DATA?
Returns the front panel display image ("screen shot")
Parameter Typical Return
(none) (A definite-length binary block containing the image.)
Definite-length block data allows any type of device-dependent data to be transmitted as a series of
8-bit binary data bytes. This is particularly useful for transferring large quantities of data or 8-bit
extended ASCII codes.
Capture and return the display image:
HCOP:SDUM:DATA?
l The image format (PNG or BMP) is specified by HCOPy:SDUMp:DATA:FORMat.
HCOPy:SDUMp:DATA:FORMat {PNG|BMP}
HCOPy:SDUMp:DATA:FORMat?
Specifies the image format for images returned by HCOPy:SDUMp:DATA?.
Parameter Typical Return
{PNG|BMP}, default PNG PNG or BMP
Set the display image format to BMP
HCOP:SDUM:DATA:FORM BMP
228 Agilent 33500 Series Operating and Service Guide
