20
Chapter 1 Quick Start
Basic Operation
1
To Select a Slot and Channel
When the instrument is first turned on, the display shows the model
number and the slot number of the controller board.
Use the knob to select a channel on the active slot. For example, with the
display shown above, turning the knob to the right will select the first of
the individual built-in digital I/O ports.
The “DIN” indicates the port is set for a digital input operation. As the
knob is turned, the additional ports are displayed followed by any
installed plug-in modules.
If you have installed one or more plug-in modules, you can select the
module by pressing the right arrow key. For example, if an N2260A (40-
channel MUX module) is installed in slot 1, pressing the right arrow key
will show the module name and slot number.
Turning the knob will then step through the individual channels on that
module.
3499
0
DIN
090
N2260A 1
MUX
100
OPEN
To Next Page
