Chapter 9 Specifications
N2276A Dual 1-to-6(4) Microwave MUX/Attenuator Module
4
9
N2276A Dual 1-to-6(4) Microwave MUX/
Attenuator Module
N2276B Microwave MUX/Attenuator Module
The switching and attenuation characteristics of the N2276B are
determined by the switches and attenuators installed in it. Please refer
to the switch’s and/or attenuator’s data sheet for the specifications of
your customized N2276B module.
Total Channels:
Dual 1-to-6 (Dual 1-to-4 when with option 204)
Connector Type:
SMA (female)
Frequency Range:
DC to 20 GHz
Insertion Loss:
0.3 dB + 0.015*Frequency (GHz)
Isolation:
100 dB min. DC to 12 GHz
80 dB min. 12 GHz to 15 GHz
70 dB min. 15 GHz to 20 GHz
SWR:
1.2 max DC to 4 GHz
1.35 max 4 to 12.4 GHz
1.45 max 12.4 to 18 GHz
1.7 max 18 to 20 GHz
Repeatability:
(5 million cycles at 25
o
C)
0.03 dB maximum
Switch Speed:
25ms
Switch Life:
5 million cycles
