Chapter 9 Specifications
N2263A 32-bit Digital I/O Module
4
9
N2263A 32-bit Digital I/O Module
I/O LINES
Bit Number:
32
Maximum Voltage:
Line-Chassis: + 42 V dc
Maximum Sink Current:
Per Bit: 600 mA
Output Characteristics:
Vout (high):
Vout (low):
≥ 2.4 V @ I ≤ 10 mA output
≤ 0.8 V @ I ≤ 600 mA input
Input Characteristics:
Vin (high):
Vin (low):
≥ 2.0 V
≤ 0.8 V
HANDSHAKE LINES
Maximum Voltage:
Line-Chassis: +5 V dc
Output Characteristics:
Vout (high):
Vout (low):
Iout (low):
≥ 2.4 V @ I ≤ 400 µA output
≤ 0.5 V @ I ≤ 1 mA input
< 25 mA (when shorted to +5 V)
Input Characteristics:
Vin (high):
Vin (low):
≥ 2.0 V
≤ 0.8 V
