Specifications
Specification for the mainframe and all plug-in modules are given in this
chapter for easy reference. This chapter includes:
•
3499A/B/C Mainframe, on page 301
•
N2260A 40-Channel MUX Module, on page 303
•
N2261A 40-Channel GP Relay Module, on page 305
•
N2262A 4 x 8 2-Wire Matrix Switch Module, on page 307
•
N2263A 32-bit Digital I/O Module, on page 309
•
N2264A Multifunction Module, on page 310
•
N2265A Multifunction Module, on page 313
•
N2266A 40-Channel MUX Module, on page 315
•
N2267A 8-Channel High Current GP Module, on page 317
•
N2268A 50Ω 3.5GHz Dual 1-to-4 MUX Module, on page 319
•
N2270A 10-Channel High Voltage MUX Module, on page 321
•
N2272A 1 GHz RF 1-to-9 MUX Module, on page 323
•
N2276A Dual 1-to-6(4) Microwave MUX/Attenuator Module, on page 325
•
N2276B Microwave MUX/Attenuator Module, on page 325
•
N2280A Quadruple 1-to-2 Optical Switch Module, on page 326
•
N2281A Dual 1-to-4 Optical Switch Module, on page 327
•
N2282A 1-to-8 Optical Switch Module, on page 328
•
44470A 10-Channel MUX Module, on page 329
•
44470D 20-Channel MUX Module, on page 331
•
44471A 10-Channel GP Relay Module, on page 333
•
44471D 20-Channel GP Relay Module, on page 335
•
44472A Dual 4-Channel VHF Switch Module, on page 337
•
44473A 4 x 4 2-Wire Matrix Switch Module, on page 339
•
44474A 16-Bit Digital I/O Module, on page 341
•
44475A Breadboard Module, on page 342
•
44476A Microwave Switch Module, on page 344
•
44476B Microwave Switch Module, on page 344
•
44477A Form-C Relay Module, on page 345
•
44478A/B 1.3 GHz Dual 4-to-1 MUX Modules, on page 347
