Chapter 7 Plug-in Modules
44476B Microwave Switch Module
7
44476B Microwave Switch Module
The 44476B is not supplied with microwave switches. You must provide
your own microwave switches, mount them on the assembly, and connect
one of the module’s Form C relay drive circuits to each switch.
The 44476B panel has two 53.8 X 9.6 mm cutouts for a set of microwave
switches. The recommended Agilent microwave switches are listed
below.
The 3499A/B/C identifies this module as a 44471A on the front-panel
display. Changing the state of channels other than channels 00 through
02 does not generate an error, but has no effect.
Specifications for the 44476B are dependent upon the switches used.
Refer to the switch data sheets for more information.
Microwave Switch Ports Frequency
8762A 3 DC-4 GHz
8762B 3 DC-18 GHz
8762C 3 DC-26.5 GHz
8762F
a
a. Except the 8762F Microwave Switch with 75 Ω characteristic impedance, all
others are 50 Ω.
3 DC-4 GHz
8763B 4 DC-18 GHz
8763C 4 DC-26.5 GHz
8764B 5 DC-18 GHz
8764C 5 DC-26.5 GHz
