Agilent Technologies Agilent 3499A User Manual

321
Chapter 9 Specifications
N2270A 10-Channel High Voltage MUX Module
4
9
N2270A 10-Channel High Voltage MUX
Module
INPUT CHARACTERISTICS
Total Channels:
10
Maximum Switching
Voltage:
Terminal-Terminal or
Terminal-Chassis:
1000 V peak (per IEC1010 for
Pollution Degree I)
Maximum Switching
Current:
Per Channel:
Per Module:
1 A
1 A
Maximum Switching Power:
Per Channel:
Per Module:
10 W
10 W
Thermal Offset:
Per Channel: 200 µV
Initial Closed Channel
Resistance:
< 1 Ω
Relay Life:
Signal load, 1V 10mA: 10
8
Maximum Scan Rate:
100 Chans/sec
DC CHARACTERISTICS
Open Channel,
Channel-Channel:
(with 1 channel closed)
< (40
o
C, 50% RH):
< (40
o
C, 80% RH):
> 10
10
Ω
> 10
9
Ω
Channel-Chassis:
(with 1 channel closed)
< (40
o
C, 50% RH):
< (40
o
C, 80% RH):
> 10
10
Ω
> 10
9
Ω
