Agilent Technologies Agilent 3499A User Manual

320
Chapter 9 Specifications
N2268A 50Ω 3.5GHz Dual 1-to-4 MUX Module
9
AC CHARACTERISTICS
a
Bandwidth (-3dB):
50 Ω source, 50 Ω termination: 3.5 GHz
Insertion Loss:
(with 50Ω termination)
1 GHz:
2 GHz:
3 GHz:
3.5 GHz:
0.9 dB
1.2 dB
1.4 dB
1.7 dB
Crosstalk:
(with 50Ω termination)
DC-2 GHz:
2 GHz-3.5 GHz:
-64 dB
-50 dB
VSWR:
1 GHz:
2 GHz:
3.5 GHz:
1.20
1.35
1.35
Capacitance:
Center-Shield:
Center-Center:
20 pF
0.06 pF
Rise Time:
<150 ps
Signal Delay:
<1.5 ns
a. With chassis of all instruments connected, and with Lo Terminal of the input connected to Lo Terminal of the output
(either directly or via the 3499A/B/C switching channels).
